Description
| Ref No. | A mm | B mm | C mm | D mm | E mm |
|---|---|---|---|---|---|
| DF46 | 4.0 | 3.4 | 2.6 | 1.0 | 2.6 |
| DF46S | 4.3 | 3.0 | 1.6 | 1.0 | 2.7 |
| DF29 | 5.1 | 3.5 | 1.9 | 2.5 | 4.9 |
| DF1 | 5.5 | 4.3 | 2.5 | 1.0 | 3.2 |
| DF32 | 5.5 | 4.5 | 3.3 | 1.1 | 2.5 |
| DF2 | 7.0 | 5.0 | 3.0 | 1.0 | 3.5 |
| DF35 | 7.5 | 6.0 | 3.6 | 3.4 | 6.4 |
| DF4 | 8.0 | 6.2 | 3.0 | 1.2 | 4.0 |
| DF20 | 8.0 | 6.2 | 3.3 | 1.6 | 4.1 |
| DF14 | 8.0 | 6.1 | 3.1 | 1.6 | 4.8 |
| DF15 | 8.1 | 5.6 | 4.0 | 1.6 | 6.5 |
| DF5 | 8.2 | 6.0 | 4.0 | 1.4 | 3.4 |
| DF6 | 8.2 | 6.1 | 4.0 | 2.7 | 5.6 |
| DF17 | 8.2 | 7.0 | 4.3 | 4.3 | 7.0 |
| DF36 | 8.5 | 6.0 | 4.0 | 2.0 | 5.4 |
| DF7 | 8.5 | 7.4 | 3.1 | 2.7 | 5.8 |
| DF33 | 8.6 | 7.5 | 3.1 | 3.2 | 6.5 |
| DF8 | 9.1 | 6.8 | 4.8 | 1.2 | 4.0 |
| DF22 | 9.1 | 6.1 | 3.3 | 2.6 | 6.5 |
| DF13 | 10.3 | 7.0 | 4.8 | 2.5 | 5.3 |
| DF9 | 10.4 | 9.1 | 5.0 | 0.9 | 4.0 |
| DF18 | 11.1 | 9.3 | 5.0 | 0.8 | 4.5 |
| DF12 | 11.9 | 9.0 | 6.0 | 2.0 | 6.2 |
| DF21 | 13.0 | 10.0 | 6.5 | 6.5 | 12.0 |
| DF28 | 13.3 | 10.6 | 7.2 | 2.5 | 6.0 |
| DF25 | 15.0 | 11.5 | 7.9 | 1.5 | 5.5 |
| DF47 | 15.0 | 11.5 | 7.8 | 2.5 | 7.0 |
| DF26 | 18.5 | 15.0 | 10.0 | 3.0 | 6.0 |
| DF37 | 20.0 | 11.5 | 6.0 | 3.6 | 9.0 |
| DF11 | 24.5 | 20.5 | 14.6 | 3.5 | 7.2 |
| DF38 | 26.9 | 20.8 | 13.5 | 6.3 | 13.5 |
| DF27 | 33.2 | 31.0 | 26.1 | 2.0 | 5.3 |
