Multi Groove Rollers

Use diagrams and table below for sizes.

We also offer custom multi-rollers.

Category:

Description

Multi Groove Diagram

Ref. No⌀A
mm
⌀B
mm
⌀R
mm
⌀F
mm
L
mm
G
mm
No. of
Grooves
⌀C
mm
D
mm
W2813.55.09.034.07.05
V3213.73.310.015.64.82
W2514.03.59.020.04.039.04.0
W2715.04.39.020.03.64
W3515.05.08.026.53.08
W615.83.17.630.33.56
W3715.96.39.020.022.04.64
V1316.03.58.019.03.53
W3116.05.310.021.034.06.05
W316.06.29.527.04.84
W916.03.59.536.56.35
V2916.54.510.512.54.72
V2816.54.510.515.84.23
W2916.54.510.518.04.04
V3016.54.510.524.06.04
V917.05.08.020.010.02
V1017.06.08.023.012.02
W2117.63.510.023.89.0-16.04.0
W2217.63.510.023.814.06.026.04.0
W2317.63.510.023.820.06.036.04.0
W2417.63.511.023.822.05.046.04.0
W3021.05.38.220.09.02
W3621.05.39.021.05.03
W4422.06.514.040.03.7510
W3229.06.216.026.012.5210.03.0
W5329.56.514.092.611.08
W5429.56.514.099.67.612
W5529.56.56.098.66.016
W5230.06.210.036.56.04
W4530.06.518.072.011.66
